ssd固態硬盤 3ME4固態盤 電子硬盤 innodisk
產品價格：￥（人民幣）
商鋪名稱：北京齊昂電子科技有限公司
聯系人：苗經理（先生）
聯系手機：
固定電話：
企業郵箱：546288802@qq.com
聯系地址：北京昌平區西三旗建材城東路新龍大廈B座1022室
郵編：100089
聯系我時，請說是在電子快手網上看到的，謝謝！
商品詳情
- 2.5” SATA III soultion for industrial field
- 7mm height mechinicial design
- DRAM-less, high-level data integrity
- L3?architecture extends lifespan
- Excellent IOPS boosts system performance
- Built-in thermal sensor
- Support S.M.A.R.T, TRIM, NCQ and iData Guard
工業用閃存模塊?>?固態硬盤SSD?>?2.5" SATA SSD 3ME4
2.5" SATA SSD 3ME4
產品特色
Overview:
Innodisk 2.5” SATA SSD 3ME4 is characterized by L3 architecture with the latest SATA III (6.0GHz) Marvell NAND controller. Innodisk’s exclusive L3 architecture is L2 architecture multiplied LDPC (Low Density Parity Check). L2 (Long Life) architecture is a 4K mapping algorithm that reduces WAF and features a real-time wear leveling algorithm to provide high performance and prolong lifespan with exceptional reliability.
規格：
| Model Name | 2.5" SATA SSD 3ME4 |
| Interface | SATA III 6.0 Gb/s |
| Flash Type | MLC |
| Type | 2.5" |
| Capacity | 8GB~256GB |
| Max. Channels | 2 |
| Sequential R/W (MB/sec, max.) | 530/210 |
| Max. Power Consumption | 0.8 W (5V x 160 mA ) |
| Thermal Sensor | Y |
| External DRAM Buffer | N |
| H/W Write Protect | N |
| iCell | N |
| ATA Security | Y |
| S.M.A.R.T. | Y |
| Dimension (WxLxH/mm) | 69.85 x 100.10 x 6.9 |
| Vibration | 20G@7~2000Hz |
| Shock | 1500G@0.5ms |
| MTBF | >3 million hours |
| Storage Temperature | -55°C ~ +95°C |
| Operation Temperature |
Standard Grade: 0°C ~ +70°C; Industrial Grade: -40°C ~ +85°C |
產品料號：
| Operation Temp. | 8GB | 16GB | 32GB | 64GB | 128GB | 256GB |
|
Standard Grade (0°C ~ +70°C) |
DES25- 08GM41BC1SC |
DES25-16GM41BC1SC DES25-16GM41BC1DC |
DES25-32GM41BC1DC | DES25-64GM41BC1DC | DES25-A28M41BC1DC | DES25-B56M41BC1DC |
|
Industrial Grade (-40°C~+85°C) |
DES25- 08GM41BW1SC |
DES25-16GM41BW1SC DES25- 16GM41BW1DC |
DES25-32GM41BW1DC | DES25-64GM41BW1DC | DES25-A28M41BW1DC | DES25-B56M41BW1DC |
| Operation Temp. | 8GB | 16GB | 32GB | 64GB | 128GB | 256GB |
|
Standard Grade (0°C ~ +70°C) |
DES25- 08GM41BC1SC |
DES25-16GM41BC1SC DES25-16GM41BC1DC |
DES25-32GM41BC1DC | DES25-64GM41BC1DC | DES25-A28M41BC1DC | DES25-B56M41BC1DC |
|
Industrial Grade (-40°C~+85°C) |
DES25- 08GM41BW1SC |
DES25-16GM41BW1SC DES25- 16GM41BW1DC |
DES25-32GM41BW1DC | DES25-64GM41BW1DC | DES25-A28M41BW1DC | DES25-B56M41BW1DC |
