?ABB控制器單元PM858K02 3BSE082896R1的參數如下?：

?一、基礎信息?

• ?品牌?：ABB
• ?型號?：PM858K02 3BSE082896R1
• ?系列?：AC800M系統模塊
• ?類型?：冗余控制器單元，支持CPU冗余以提高系統可用性

?二、電氣參數?

• ?電源?：

  • 輸入電壓范圍：12~48V DC（典型工作電壓12V/24V/48V），也支持24Vdc/120Vac
  • 功耗：+24V時典型值210mA，最大值360mA；功率典型值5.1瓦，最大值8.6瓦
  • 內置備用電池：鋰，3.6V，用于保持實時時鐘和關鍵數據

• ?時鐘頻率?：33兆赫

?三、通信接口?

• ?以太網端口?：

  • 數量：2個（RJ45接口，CN1、CN2）
  • 速率：10 Mbit/s（IEEE 802.3標準）
  • 用途：連接控制網絡，支持冗余以太網通信

• ?串行端口?：

  • 數量：2個（RJ45接口，COM3、COM4）
  • COM3：帶有調制解調器控制信號的RS-232C端口，波特率75-19200
  • COM4：隔離端口，用于連接配置工具，波特率9600，光隔離，不支持RTS-CTS

• ?其他通信接口?：

  • 支持Profibus DP、FF、Modbus等多種現場總線協議（需擴展模塊）
  • CEX總線擴展槽：1個，可連接多達12個通信模塊

?四、性能參數?

• ?布爾運算速度?：1000個布爾運算需0.36毫秒

• ?內存?：

  • RAM：16MB，可用于應用程序
  • Flash PROM：4MB，用于固件存儲

• ?應用程序與任務?：

  • 每個控制器的應用程序數量：32
  • 每個應用程序的程序數：64
  • 每個應用程序的圖表數量：128
  • 每個控制器的任務數：32
  • 不同循環時間的數量：32
  • 應用程序周期時間：可低至1毫秒

• ?模塊總線掃描率?：0-100毫秒（實際時間取決于I/O模塊的數量）

• ?I/O容量?：

  • 中央處理器：7個光學Modulebus上的I/O容量最多96個（單個PM866）或84個（冗余PM866）I/O模塊
  • 電氣模塊總線上的電源電流：24V時1.0A，5V時1.5A

?五、環境適應性?

• ?工作溫度?：0°C至+60°C（工業級寬溫設計），也有說法為-40℃~85℃
• ?存儲溫度?：-40°C至+70°C，也有說法為-40℃~85℃
• ?相對濕度?：5%至95%，非冷凝
• ?防護等級?：IP20（需安裝在控制柜內）
• ?振動?：符合IEC/EN 61131-2標準

?六、功能與優點?

• ?可靠性和簡單的故障診斷程序?：確保設備的穩定運行和快速故障排除
• ?模塊化設計?：允許逐步擴展，適應不同規模的工業自動化需求
• ?全面的EMC認證?：確保設備在電磁干擾環境下的穩定運行
• ?基于標準的硬件?：用于實現通信連接（以太網、PROFIBUS DP等）
• ?冗余支持?：CPU、CEX-Bus、通信接口和S800 I/O均支持冗余配置
• ?實時時鐘穩定性?：100 ppm（約1小時/年）

ASTO-11C
131-6BH00-0BA0
193-6BP00-0BA0
2080-LC50-48QWB
220-0AA22-2AA0
255-0AA00-4BA1
2IF4564-1ZA63-5BG6
300-0SF01-0AA0
314-1AE04-0AB0
321-1CH00-0AA0
372-0AA30-0AA1
3BHB006309R0001
3BHB006338R0001
3BHB024711R0020
3BSE048845R1---CI868
6181P-17TPXP
6ES7193-6BP00-0BA0
6ES7414-4HM14-0AB0
6FC5372-0AA30-0AA1
6FX2001-6RB12-6MA0
6GK7542-5FX00-0XE0
901-1BB11-2AA0
A5E42740130
A5E42740240
A60L-0001-0511
ARND-3110
ARND-3120C
ARND-4037A
ARND-8127A
ARND-8219A
ASTO-11C
ATV71HU55Y
CI868
CX9020-0112
EL2809
FR-D720-042-NA
GA50X4018ABBA
HDS02.2-W040N-HS12-01-FW
HIER329036P0004
JAMSC-120DAI74300
LDZ10501382
R4D500-AT03-01
SK-R9-FAN11-F7A

Brand: ABB
Model: PM858K02 3BSE082896R1
Series: AC800M System Module
Type: Redundant controller unit, supporting CPU redundancy to improve system availability
2、 Electrical beters
Power supply:
Input voltage range: 12~48V DC (typical operating voltage 12V/24V/48V), also supports 24Vdc/120Vac
Power consumption: typical value of 210mA at+24V, maximum value of 360mA; power typical value of 5.1W, maximum value of 8.6W
Built in backup battery: lithium, 3.6V, used to maintain real-time clock and critical data
Clock frequency: 33 MHz
3、 Communication interface
Ethernet port:
Quantity: 2 (RJ45 interface, CN1、CN2）
Speed: 10 Mbit/s (IEEE 802.3 standard)
Purpose: To connect control networks and support redundant Ethernet communication
Serial port:
Quantity: 2 (RJ45 interface, COM3、COM4）
COM3: RS-232C port with modem control signal, baud rate 75-19200
COM4: Isolation port, used to connect configuration tools, baud rate 9600, optical isolation, does not support RTS-CTS
Other communication interfaces:
Supports multiple fieldbus protocols such as Profibus DP, FF, Modbus, etc. (requires module expansion)
CEX bus expansion slot: 1, can connect up to 12 communication modules
4、 Perbance beters
Boolean operation speed: 1000 Boolean operations require 0.36 milliseconds
Memory:
RAM：16MB， Can be used for applications
Flash PROM：4MB， Used for firmware storage
Applications and Tasks:
Number of applications per controller: 32
Number of programs per application: 64
Number of charts per application: 128
Number of tasks per controller: 32
Number of different cycle times: 32
Application cycle time: can be as low as 1 millisecond
Module bus scan rate: 0-100 milliseconds (actual time depends on the number of I/O modules)
I/O capacity:
Central processing unit: Up to 96 I/O modules (single PM866) or 84 I/O modules (redundant PM866) on 7 optical Modules
Power supply current on the electrical module bus: 1.0A at 24V and 1.5A at 5V
5、 Environmental adaptability
Working temperature: 0 ° C to+60 ° C (industrial grade wide temperature design), also known as -40 ℃~85 ℃
Storage temperature: -40 ° C to+70 ° C, also known as -40 ° C to 85 ° C
Relative humidity: 5% to 95%, non condensing
Protection level: IP20 (to be installed inside the control cabinet)
Vibration: Complies with IEC/EN 61131-2 standard
6、 Features and advantages
Reliability and simple fault diagnosis program: ensuring stable operation of equipment and rapid troubleshooting
Modular design: allows for gradual expansion to adapt to industrial automation needs of different scales
Comprehensive EMC certification: ensuring stable operation of equipment in electromagnetic interference environments
Standard based hardware: used to achieve optimal communication connections (Ethernet, PROFIBUS DP, etc.)
Redundancy support: CPU, CEX Bus, communication interface, and S800 I/O all support redundant configuration
Real time clock stability: 100 ppm (approximaby 1 hour/year)
