控制器單元PM851AK01 3BSE066485R1

PM851A K01 AC800M控制器單元3BSE066485R1

PM851AK01 3BSE066485R1 Communications Controllers

ABB 邏輯控制器 PM851AK01 3BSE066485R1 系統控制模塊

ABB 全新原裝AC800M控制器單元 PM851AK01 3BSE066485R1

?ABB 邏輯控制器 PM851AK01 3BSE066485R1 系統控制模塊參數如下?：

?一、基礎信息?

• ?料號編號?：3BSE066485R1
• ?品牌?：ABB
• ?產品類型?：工業控制器，屬于ABB AC800M系列PLC（可編程邏輯控制器）的一部分
• ?冗余性?：不高
• ?時鐘頻率?：24MHz

?二、處理器與內存?

• ?處理器類型?：MPC860
• ?內存?：
  • ?RAM?：16MB（800xA5.1FP4），可用于應用程序
  • ?閃存?：10,337MB（800xA5.1FP4），用于存儲

?三、電源與功耗?

• ?電源供應器?：+24V
• ?功率消耗?：
  • ?+24V類型?：最大值180/300mA
  • ?功率耗散類型?：4.32瓦（最大7.2瓦）
• ?冗余電源狀態輸入?：是
• ?內置電池?：鋰，3.6伏

?四、通信接口?

• ?以太網端口?：
  • ?數量?：2個（RJ45接口，用于連接控制網絡）
  • ?說明?：PM851/PM851A僅限于一個以太網（CN1）端口，因此冗余以太網不可用
• ?串行端口?：
  • ?數量?：2個（RJ45接口，COM3、COM4）
  • ?COM3?：帶有調制解調器控制信號的RS-232C端口
  • ?COM4?：隔離端口，用于連接配置工具
• ?CEX總線通信?：
  • ?模塊數量?：12個單CEX總線模塊
  • ?電源電流?：最大2.4安培
• ?I/O群集?：
  • ?CPU?：1個電氣，7個光學I/O群集on Modulebus with red
  • ?模塊總線上的I/O容量?：最多96個I/O模塊

?五、性能參數?

• ?布爾運算速度?：0.46毫秒
• ?模塊總線掃描速率?：0-100毫秒（實際時間取決于I/O模塊數）
• ?電氣模塊總線上的電源電流?：
  • ?24V?：最大1.0A
  • ?5V?：最大1.5A
• ?應用程序與任務?：
  • ?每個控制器的應用程序數量?：32
  • ?每個應用程序的程序數?：64
  • ?每個應用程序的圖數?：128
  • ?每個控制器的任務數?：32
  • ?不同周期的次數?：32
  • ?應用程序循環時間?：可降低到1毫秒

?六、環境適應性?

• ?操作溫度?：+5至+55℃（+41至+131℉）
• ?存儲溫度?：-40至+70℃（-40至+158℉）
• ?溫度變化?：3℃/分鐘
• ?相對濕度?：5%至95%，非冷凝
• ?振動?：
  • ?10Hz < f < 50Hz?：0.0375毫米振幅
  • ?50Hz < f < 150Hz?：0.5g加速度
  • ?5Hz < f < 500Hz?：0.2g加速度
• ?防護等級?：IP20（根據EN 60529、IEC 529標準）
• ?海拔高度?：根據IEC/EN 61131-2標準，2000米（6,562英尺）

?七、功能與優點?

• ?可靠性和簡單故障診斷程序?：確保系統的穩定運行和快速故障排除
• ?模塊化設計?：允許逐步擴展，適應不同規模的工業自動化需求
• ?IP20類保護?：提供必要的防護，無需額外的存儲模塊
• ?控制器可配置性?：可通過800xA控制構建器進行配置
• ?全面的EMC認證?：確保設備的穩定運行和電磁兼容性
• ?基于標準的硬件?：用于實現通信連接（以太網、PROFIBUS DP等）

090-0XX84-0BC0
031-6DV62-0
1326AB-B740C-S2L
1762-IF4
177230-01-01-05
1784-CF128
2094-BC02-M02-S
22B-D010N104
3HAC025917-001
6177R-MMPXP
6EP4135-0GB00-0AY0
6RA7031-6DV62-0
6SE7090-0XX84-0BC0
81007-465-51-R
8C-PAONA1
EM20-S-004
FS450R12KE3/AGDR-71C
KST-MK2-075
MPF-B540K-MJ74BA
PSR16-600-70
PSR30-600-11ABB
PSR60-600-70
PW482-50
SDCS-PIN-20XB
SM560-S
TCSESPU053F1CU0
TM2AMO1HT
VPM02D20AA00
ACS-AP-S
3BHE039426R0101
5SDF0345D00063BHL000200P0001
193-6AG50-0AA0
222-1HH32-0XB0
232-4HB32-0XB0
288-0CD10-0AA0
2TLA010026R0000RT6
3BHB016120R0002
3BHB017688R0001
3BHB030310R0001
3BHL000200P0001
642-5DC10-1AC0
6EP3333-7SB00-0AX0
6ES7193-6AG50-0AA0
6ES7400-1JA11-0AA0
6ES7655-5DX40-2AA0
6GK1901-0DB20-6AA0
6GK5204-2AA00-2GF2
6GK5204-2AA00-2YF2
6GK5738-1GY00-0AA0
738-1GY00-0AA0
800T-FXT6A5
901-0DB20-6AA0
A5E00496051
A5E02363383
A860-2005-T301
ACBU-A2
ACS-AP-S
ATS48D88Q
ATV61HC22N4---ATV61C22N4
 E84AHWMC1534V-V003
CDP
CIMr-AB4A0414ABA
CP-C24/10.0
E82MV402-4B001
E84AHWMC1534V-V003
EPXPNS001
IC695ACC302
ISD371024HK21
NDPI-02
SACEPR121/P
SKD60
SPIET800
TBUP357-1A20-AB20S
TBUX297319
TSXASY800
TSXPCX1031
UHW241Z-UHW241M3
UTTIH-B20FK
X20AI8321
X20BR9300
X20DIF371
X20DOF322
XPSATE5110
REM615
140CPS11100
140CPU11302
140DA084000---140DAO84000
140DAI35300
1734-IE4C
1XP8012-10/1024
20AC8P7C0AYNANC0
2TLA020009R0600
322-1BL00-0AA0
331-1KF02-0AB0
3AX1103-2F
3BHB006338R0002
3BHE004468R0021
3BHE039426R0101
3BSE069052R1----DI818
3BSE069053R1----DO818
3BSE072270R1
3BSE081638R1
440-2UD31-1CA1
515-2FM02-0AB0
6AU1445-2AD00-0AA1
6ES7315-2AG10-0AB0
6ES7315-2AG10-0AB0
6ES7322-1BL00-0AA0
6ES7331-1KF02-0AB0
6ES7515-2FM02-0AB0
6ES7972-0BA12-0XA0
6ES7972-0BB12-0HA0------6ES7972-0BB12-0XA0
6ES7972-0BB12-0XA0  
7ME6920-1AA10-1AA0
844D-B5CC2LS
BMXCRA31210
CIMR-VB4A0018FBA
DI818
DO818
E43H4A-05-A46
FDPI-02
FR-D740-0.4K-CHT
FR-D740-0.75K-CHT
HIEE300661R0001---UPC090AE01
HIEE300744R0001
HIEE300910R0001
HIEE400103R0001
HIEE400106R0001
HIEE400995R0002UMB015BE02
HIEE401091R0002
HIEE450964R0001
HIEE451116R0001
MCSESM083F23F0
MPL-B420P-MK72AA
PSR85-600-11
TSX08ED12R8
TSX3710001
TSXDEY16D2
TSXDSY16R5
TSXPSY2600

The beters of the ABB logic controller PM851AK01 3BSE066485R1 system control module are as follows:
1、 Basic Inbation
Part number: 3BSE066485R1
Brand: ABB
Product type: Industrial controller, part of ABB AC800M series PLC (Programmable Logic Controller)
Redundancy: not high
Clock frequency: 24MHz
2、 Processor and Memory
Processor type: MPC860
Memory:
RAM: 16MB (800xA5.1FP4), suitable for application programs
Flash memory: 10337MB (800xA5.1FP4), used for storage
3、 Power supply and power consumption
Power supply:+24V
Power consumption:
+24V type: maximum value of 180/300mA
Power dissipation type: 4.32 watts (maximum 7.2 watts)
Redundant power status b: Yes
Built in battery: lithium, 3.6V
4、 Communication interface
Ethernet port:
Quantity: 2 (RJ45 interface, used for connecting control network)
Explanation: PM851/PM851A is limited to one Ethernet (CN1) port, therefore redundant Ethernet is not available
Serial port:
Quantity: 2 (RJ45 interface, COM3、COM4）
COM3: RS-232C port with modem control signal
COM4: Isolation port, used to connect configuration tools
CEX bus communication:
Number of modules: 12 single CEX bus modules
Power supply current: maximum 2.4 amperes
I/O cluster:
CPU: 1 electrical, 7 optical I/O clusters on Modulabus with red
I/O capacity on module bus: up to 96 I/O modules
5、 Perbance beters
Boolean operation speed: 0.46 milliseconds
Module bus scan rate: 0-100 milliseconds (actual time depends on the number of I/O modules)
Power supply current on the electrical module bus:
24V: Maximum 1.0A
5V: Maximum 1.5A
Applications and Tasks:
Number of applications per controller: 32
Number of programs per application: 64
Number of images per application: 128
Number of tasks per controller: 32
Number of different cycles: 32
Application cycle time: can be reduced to 1 millisecond
6、 Environmental adaptability
Operating temperature:+5 to+55 ℃ (+41 to+131 ℉)
Storage temperature: -40 to+70 ℃ (-40 to+158 ℉)
Temperature change: 3 ℃/min
Relative humidity: 5% to 95%, non condensing
Vibration:
10Hz<f<50Hz: 0.0375mm amplitude
50Hz<f<150Hz: 0.5g acceleration
5Hz<f<500Hz: 0.2g acceleration
Protection level: IP20 (according to EN 60529, IEC 529 standards)
Altitude: According to IEC/EN 61131-2 standard, 2000 meters (6562 feet)
7、 Features and advantages
Reliability and simple fault diagnosis program: ensuring stable system operation and rapid troubleshooting
Modular design: allows for gradual expansion to adapt to industrial automation needs of different scales
IP20 protection: Provides necessary protection without the need for additional storage modules
Controller Configurability: Configurable through 800xA Control Builder
Comprehensive EMC certification: ensuring stable operation and electromagnetic compatibility of equipment
Standard based hardware: used to achieve optimal communication connections (Ethernet, PROFIBUS DP, etc.)
